Heliport Perimeter Light Model 1000
This product is available in our webstore – Shop Now
Outlines the Landing Area
The Heliport Perimeter Light, Model 1000 has a low profile and outlines the heliport with a string of yellow lights.
Surface Mounted
It has two extension tabs to permit bolting to a concrete slab for easy surface mount installation.
Optically Designed Heat Resistant Glass Lens
The optically designed lens has a high vertical angle to accommodate the steeper landing slope of the helicopter approaches. It is aviation yellow, heat resistant glass. Available in Blue, Red and Yellow. The Perimeter Light meets and exceeds recommendations by worldwide authorities.
Cast Aluminum Construction
The fixture is housed in a heavy-machined cast aluminum case that is weather tight and has two mounting tabs. A stainless steel wire guard protects the lens from breakage. It is finished in orange polyester powder coating for durability.
Specifications
Case – Heavy Cast Aluminum
Lens – Heat Resistant Glass
Lamp – 35 Watt Incandescent
Lens Guard – Stainless Steel
Power – 120 VAC, or other
Dimensions:
Height: 6 Inches
Diameter: 6 Inches
Weight: 8 pounds
Finish: Polyester Powder Coating
